Product

WIDESCAN

제품 상세 이미지

Specification

주요 스펙

기술: LASER scanner, time-of-flight measurement (7 laser curtains)
감지모드: Motion, presence, height and speed
Typ. mounting high: 2 m to 10 m
최대감지영역: Width: 1 x mounting height; Depth: 1 x mounting height
Thickness of first curtain: 0.5 cm / m (mounting height)
최소감지물체사이즈: 70 cm x 30 cm x 20 cm
Emission characteristics (IEC 60825-1): IR LASER: Wavelength 905 nm; output power <0.1 mW; Class 1 Visible LASER: Wavelength 635 nm; output power <1 mW; Class 2
Bluetooth communication: Operating bandwidth: 2402 MHz – 2480 MHz Maximum transmitted power: 12 dBm
공급전압: 12 V - 24 V AC -10%/+20% ; 12 V - 30 V DC -10%/+20% @ sensor terminal (The Equipment must be powered by an approved Class II SELV limited power source. This requirement consists of the need for double insulation between primary voltages and the Equipment supply. The supply current should be limited to 1.5 A)
소비전력: heating off: < 2.5 W heating auto: typ. < 10 W, max. 15 W
응답시간: Typ. 230 ms; max. 800 ms (depending on immunity settings)
출력: 2 solid-state relays ( galvanic isolation - polarity free ) 24 V AC/ 30 V DC (max. switching voltage) - 100 mA (max. switching current) - in switching mode: NO/NC - in frequency mode: pulsed signal (f= 100 Hz +/- 10%) 1 electro-mechanic relay (galvanic isolation - polarity free) 42 V AC/DC (max. switching voltage) - 500 mA (max. switching current)
Test input: 30 V DC (max. switching voltage) - low 10 V (voltage threshold)
Rotation angles on bracket: 45° to the right, 15° to the left ( lockable )
Tilt angles on bracket: -10° to +5°
보호등급: IP65
사용온도범위: -30 °C to +60 °C
Min. reflectivity factor: > 2 % (of floor and object) (measured at max. 6 m in safety field)
LED-signals: 3 coloured LEDs
Dimensions: 159 mm (H) x 208 mm (W) x 127 mm (D)
Material / Colour: PC/ASA / Black
